FUTABA 10J User Manual

58
Commonfunction
Function
PARAMETER submenu: sets those parameters
you would likely set once, and then not disturb
again.
Once you have selected the correct model you
wish to work with, the next step is setting up the
SURSHUSDUDPHWHUVIRUWKLVVSHFL¿FPRGHO
Datareset（RESET）
Thepresentmodeldataisreset.DataResetdoesNOTreset,ATLTrim,TELEMETRYmode,orSTKPOSI
Alarm.
Modeltype（TYPE）SWASH:OnlyhelicopterWING:Onlyglider
MODELTYPE:setsthetypeofprogrammingusedforthismodel.
TheT10Jhas30modelmemories,whichcaneachsupport:
●
Onepoweredaircraft(ACRO)memorytype(withmultiplewingandtailconfigurations.Seetwin
aileronservos,twinelevatorservos,ELEVON,andV-TAILforfurtherinformation.)
●
Eighthelicopterswashplatetypes,includingCCPM.SeeHelicopterMODELTYPEfordetails.
● IfyouuseCGY750,theswashtypeshouldchooseH-1. (SwashtypeischosenbysetupinCGY750.）
●
Fivegliderwingtypes.SeegliderWINGTYPEfordetails.
●
Multicoptertype.
Beforedoinganythingelsetosetupyouraircraft,firstyoumustdecidewhichMODELTYPEbestfits
thisparticularaircraft.(Eachmodelmemorymaybesettoadifferentmodeltype.)Ifyourtransmitter
isaT10JA,thedefaultisACRO.IfitisaT10JH,thedefaultisHELI(H1).
ATLTrim（ATL）
Adjustabletravellimit(ATL):makesthechannel3TRIMLEVER(THROTTLETRIM)effectiveonlyat
lowthrottle,disablingthetrimathighthrottle.Thispreventspushrodjammingduetoidlingtrim
changes.ThisfunctiondefaultstoON.Ifyouarenotusingchannel3forthrottle,youmaywant
trimoperationthesameasonallotherchannels.Todoso,setATLtoOFF.IfyouneedtheATLtobe
effectiveatthetopofthestickinsteadofthebottom,reversetheTHR-REVsetting.Notethatthis
affectsallmodelsintheradio,notjustthemodelyouarecurrentlyediting.
LCDcontrast（CONTRAST）
ContrastadjustmentLCDscreen.
● Youadjusttolegiblecontrast.setuprange-10 〜 +10
Backlight（BACK-LIT）
BacklightmodeofaLCDscreencanbechosen.
● ALWAYS/KEY-ON(Shinesforadefiniteperiodoftimeafterkeyoperation.)/OFF
Lighttime（LIT-TIME）
Setsthelengthoftimethebacklightwillstayon.
● Setuprange1 〜 30
Lightadjustment（LIT-ADJS）
Lightvolumeadjustmentofabacklight.
● Setuprange1 〜 30
Homedisplay（HOME-DSP）
Itemselectiondisplayedonahomescreen
● Futabalogo(Default),USR-NAME,RXBATT,DT5/DT6,THR/PIT(Caseofhelicopter,thepositionofa
throttleandpitch.)
PARAMETER
Parameterfunction
(Common)

FUTABA 10J Specifications

General

Channels	10
Frequency	2.4GHz
Model Memory	30
Display	LCD
Telemetry	Yes
Trainer Port	Yes
Modulation	S-FHSS
