owner’s manual for use with models 10, 20, 30 15
Navigation
EN
• Select a location on the map,
and the bar at the top of the
screen shows information
about the selected location.
Navigating a Driving Route
Driving route navigation is only
available on the eTrex 20 and eTrex
30.
Before you can use the map,
you must purchase and load City
Navigator maps. If you plan to use
an auto mount accessory with the
device, you must also purchase and
install the mount in your vehicle.
1. Select Prole Change >
Automotive.
2. Use the map to navigate to the
destination.
3. Follow the turns in the text bar
along the top of the map.
Compass
The eTrex 30 has a 3-axis,
electronic compass.
You can use a bearing pointer or a
course pointer to navigate to your
destination.
TIP: When the device is using the
automotive prole, the compass
displays GPS heading, not magnetic
heading.
Calibrating the Compass
NOTICE
Calibrate the electronic compass
outdoors. To improve heading
accuracy, do not stand near objects
that inuence magnetic elds, such
as cars, buildings, or overhead
power lines.
