GE Agile P153 User Manual

12 SCADA Communications
P50 Agile P153
9-6
P153/EN M/B
iv (=0 valid , =1 non valid or non synchronised in system case)
First Day of week is Monday
Sr. No. Function
Code
Register No. of
Regs
Format Reg.
Type
Address
Map
4
Status and
Logical Status
02
Gen Strt 1 1 bit R 12769
Strt L1 1 1 bit R 12770
Strt L2 1 1 bit R 12771
Strt L3
1
1 bit
R
12772
Strt I>1 1 1 bit R 12773
Strt I>2 1 1 bit R 12774
Strt I>3 1 1 bit R 12775
Strt I2>1 1 1 bit R 12776
Strt I2>2
1
1 bit
R
12777
Strt I2>3
1
1 bit
R
12778
Strt IN1>1
1
1 bit
R
12779
Strt IN1>2 1 1 bit R 12780
Strt IN1>3 1 1 bit R 12781
Strt IN2>1 1 1 bit R 12782
Strt IN2>2
1
1 bit
R
12783
Strt IN2>3
1
1 bit
R
12784
Strt BC 1 1 bit R 12785
THOL Alm 1 1 bit R 12786
Strt CLP 1 1 bit R 12787
Strt I< 1 1 bit R 12788
Strt CBF
1
1 bit
R
12789
I> BCBF
1
1 bit
R
12790
IN1> BCBF 1 1 bit R 12791
Test Mode 1 1 bit R 12792
CloseFail 1 1 bit R 12793
Open Fail 1 1 bit R 12794
Relay OK
1
1 bit
R
12795
Gen Trip
1
1 bit
R
12796
Trip L1 1 1 bit R 12797
Trip L2 1 1 bit R 12798
Trip L3 1 1 bit R 12799
Trip I>1
1
1 bit
R
12800
Trip I>2
1
1 bit
R
12801
Trip I>3 1 1 bit R 12802
Trip I2>1 1 1 bit R 12803
Trip I2>2 1 1 bit R 12804
Trip I2>3 1 1 bit R 12805
Trip IN1>1 1 1 bit R 12806
Trip IN1>2
1
1 bit
R
12807
