GE C60 User Manual

GE Multilin C60 Breaker Protection System 5-169
5 SETTINGS 5.6 GROUPED ELEMENTS
5
5.6.3 PHASE CURRENT
a) MAIN MENU
PATH: SETTINGS  GROUPED ELEMENTS  SETTING GROUP 1(6)  PHASE CURRENT
The C60 contains protection elements for phase time overcurrent (ANSI device 51P) and phase instantaneous overcurrent
(ANSI device 50P). A maximum of six phase time overcurrent and eight phase instantaneous overcurrent elements are
available, dependent on the CT/VT modules ordered with the relay. See the following table for details.
 PHASE CURRENT

 PHASE TOC1

See page 5–175.
MESSAGE
 PHASE TOC2

MESSAGE
 PHASE TOC3

MESSAGE
 PHASE TOC4

MESSAGE
 PHASE TOC5

Note: Seen only if slot F or slot M has an 8H or 8J CT
module installed.
MESSAGE
 PHASE TOC6

Note: Seen only if slot F or slot M has an 8H or 8J CT
module installed.
MESSAGE
 PHASE IOC1

See page 5–177.
MESSAGE
 PHASE IOC2

MESSAGE
 PHASE IOC3

MESSAGE
 PHASE IOC4

MESSAGE
 PHASE IOC5

Note: Seen only if slot F or slot M has an 8H or 8J CT
module installed.
MESSAGE
 PHASE IOC6

Note: Seen only if slot F or slot M has an 8H or 8J CT
module installed.
MESSAGE
 PHASE IOC7

Note: Seen only if slot F and slot M have 8H or 8J CT
modules installed.
MESSAGE
 PHASE IOC8

Note: Seen only if slot F and slot M have 8H or 8J CT
modules installed.
CT/VT MODULES PHASE CURRENT ELEMENTS
SLOT F SLOT M TIME
OVERCURRENT
INSTANTANEOUS
OVERCURRENT
8F/8G 8F/8G 4 4
8H/8J 6 6
8H/8J 8F/8G 6 6
8H/8J 6 6
