GE C60 User Manual

GE Multilin C60 Breaker Protection System 6-27
6 ACTUAL VALUES 6.4 RECORDS
6
6.4.5 PHASOR MEASUREMENT UNIT RECORDS
PATH: ACTUAL VALUES  RECORDS  PMU RECORDS
The number of triggers applicable to the phasor measurement unit recorder is indicated by the NUMBER OF TRIGGERS value.
The status of the phasor measurement unit recorder is indicated as follows:
PATH: ACTUAL VALUES  RECORDS  PMU RECORDS  PMU 1(2) RECORDING
6.4.6 BREAKER MAINTENANCE
PATH: ACTUAL VALUES  RECORDS  MAINTENANCE  BREAKER 1(4)
There is an identical menu for each of the breakers. The BKR 1 ARCING AMP values are in units of kA
2
-cycles. Refer to the
COMMANDS  CLEAR RECORDS menu for clearing breaker arcing current records. The BREAKER OPERATING TIME is
defined as the slowest operating time of breaker poles that were initiated to open.
 PMU
 RECORDS
NUMBER OF TRIGGERS:
0
Range: 0 to 65535 in steps of 1
MESSAGE
 PMU 1
 RECORDING
See below.
 PMU 1
 RECORDING
PMU 1 FORCE TRIGGER:
Yes
Range: No, Yes
MESSAGE
PUM 1 AVAILABLE
RECORDS: 0
Range: 0 to 65535 in steps of 1
MESSAGE
PUM 1 SECONDS
PER RECORD: 0.0
Range: 0 to 6553.5 in steps of 0.1
MESSAGE
PUM 1 LAST CLEARED:
2013/07/14 15:40:16
Range: date and time in format shown
 BREAKER 1

BKR 1 ARCING AMP φA:
0.00 kA2-cyc
MESSAGE
BKR 1 ARCING AMP φB:
0.00 kA2-cyc
MESSAGE
BKR 1 ARCING AMP φC:
0.00 kA2-cyc
MESSAGE
BKR 1 OPERATING TIME
φA: 0 ms
MESSAGE
BKR 1 OPERATING TIME
φB: 0 ms
MESSAGE
BKR 1 OPERATING TIME
φC: 0 ms
MESSAGE
BKR 1 OPERATING
TIME: 0 ms
