GE C60 User Manual

6-16 C60 Breaker Protection System GE Multilin
6.3 METERING 6 ACTUAL VALUES
6
6.3.2 SOURCES
a) MAIN MENU
PATH: ACTUAL VALUES  METERING  SOURCE SRC1
This menu displays the metered values available for each source.
Metered values presented for each source depend on the phase and auxiliary VTs and phase and ground CTs assignments
for this particular source. For example, if no phase VT is assigned to this source, then any voltage, energy, and power val-
ues will be unavailable.
b) PHASE CURRENT METERING
PATH: ACTUAL VALUES  METERING  SOURCE SRC 1  PHASE CURRENT
 SOURCE SRC 1

 PHASE CURRENT
 SRC 1
See page 6–16.
MESSAGE
 GROUND CURRENT
 SRC 1
See page 6–17.
MESSAGE
 PHASE VOLTAGE
 SRC 1
See page 6–17.
MESSAGE
 AUXILIARY VOLTAGE
 SRC 1
See page 6–18.
MESSAGE
 POWER
 SRC 1
See page 6–18.
MESSAGE
 ENERGY
 SRC 1
See page 6–19.
MESSAGE
 DEMAND
 SRC 1
See page 6–19.
MESSAGE
 FREQUENCY
 SRC 1
See page 6–20.
 PHASE CURRENT
 SRC 1
SRC 1 RMS Ia: 0.000
b: 0.000 c: 0.000 A
MESSAGE
SRC 1 RMS Ia:
0.000 A
MESSAGE
SRC 1 RMS Ib:
0.000 A
MESSAGE
SRC 1 RMS Ic:
0.000 A
MESSAGE
SRC 1 RMS In:
0.000 A
MESSAGE
SRC 1 PHASOR Ia:
0.000 A 0.0°
MESSAGE
SRC 1 PHASOR Ib:
0.000 A 0.0°
MESSAGE
SRC 1 PHASOR Ic:
0.000 A 0.0°
MESSAGE
SRC 1 PHASOR In:
0.000 A 0.0°
