GE C60 User Manual

6-22 C60 Breaker Protection System GE Multilin
6.3 METERING 6 ACTUAL VALUES
6
6.3.6 IEC 61580 GOOSE ANALOG VALUES
PATH: ACTUAL VALUES  METERING  IEC 61850 GOOSE ANALOGS
The C60 Breaker Protection System is provided with optional IEC 61850 communications capability. This
feature is specified as a software option at the time of ordering. See the Order Codes section of chapter 2
for details.
The IEC 61850 GGIO3 analog input data points are displayed in this menu. The GGIO3 analog data values are received
via IEC 61850 GOOSE messages sent from other devices.
6.3.7 SENSITIVE DIRECTIONAL POWER
PATH: ACTUAL VALUES  METERING  SENSITIVE DIRECTIONAL POWER
The effective operating quantities of the sensitive directional power elements are displayed here. The display may be useful
to calibrate the feature by compensating the angular errors of the CTs and VTs with the use of the
RCA and CALIBRATION
settings.
SOURCE ENERGY
(Positive and Negative Watthours,
Positive and Negative Varhours)
E
BASE
= 10000 MWh or MVAh, respectively
SOURCE POWER P
BASE
= maximum value of V
BASE
× I
BASE
for the +IN and –IN inputs
SOURCE VOLTAGE V
BASE
= maximum nominal primary RMS value of the +IN and –IN inputs
SYNCHROCHECK
(Max Delta Volts)
V
BASE
= maximum primary RMS value of all the sources related to the +IN and –IN inputs
 IEC 61850
 GOOSE ANALOGS
ANALOG INPUT 1
0.000
MESSAGE
ANALOG INPUT 2
0.000
MESSAGE
ANALOG INPUT 3
0.000
↓
MESSAGE
ANALOG INPUT 32
0.000
 SENSITIVE
 DIRECTIONAL POWER
DIRECTIONAL POWER 1
3Φ: 0.000 W
MESSAGE
DIRECTIONAL POWER 2
3Φ: 0.000 W
Table 6–2: FLEXELEMENT BASE UNITS (Sheet 2 of 2)
