GE C60 User Manual

5-178 C60 Breaker Protection System GE Multilin
5.6 GROUPED ELEMENTS 5 SETTINGS
5
5.6.4 NEUTRAL CURRENT
a) MAIN MENU
PATH: SETTINGS  GROUPED ELEMENTS  SETTING GROUP 1(6)  NEUTRAL CURRENT
The C60 contains protection elements for neutral time overcurrent (ANSI device 51N) and neutral instantaneous overcur-
rent (ANSI device 50N). A maximum of six neutral time overcurrent elements and eight neutral instantaneous overcurrent
elements are available, dependent on the CT/VT modules ordered with the relay. See the following table for details.
 NEUTRAL CURRENT

 NEUTRAL TOC1

See page 5–179.
MESSAGE
 NEUTRAL TOC2

MESSAGE
 NEUTRAL TOC3

MESSAGE
 NEUTRAL TOC4

MESSAGE
 NEUTRAL TOC5

Note: Seen only if slot F or slot M has an 8H or 8J CT
module installed.
MESSAGE
 NEUTRAL TOC6

Note: Seen only if slot F or slot M has an 8H or 8J CT
module installed.
MESSAGE
 NEUTRAL IOC1

See page 5–180.
MESSAGE
 NEUTRAL IOC2

MESSAGE
 NEUTRAL IOC3

MESSAGE
 NEUTRAL IOC4

MESSAGE
 NEUTRAL IOC5

Note: Seen only if slot F or slot M has an 8H or 8J CT
module installed.
MESSAGE
 NEUTRAL IOC6

Note: Seen only if slot F or slot M has an 8H or 8J CT
module installed.
MESSAGE
 NEUTRAL IOC7

Note: Seen only if slot F and slot M have 8H or 8J CT
modules installed.
MESSAGE
 NEUTRAL IOC8

Note: Seen only if slot F and slot M have 8H or 8J CT
modules installed.
CT/VT MODULES NEUTRAL CURRENT ELEMENTS
SLOT F SLOT M TIME
OVERCURRENT
INSTANTANEOUS
OVERCURRENT
8F/8G 8F/8G 4 4
8H/8J 6 6
8H/8J 8F/8G 6 6
8H/8J 6 8
