6-8 C60 Breaker Protection System GE Multilin
6.2 STATUS 6 ACTUAL VALUES
6
6.2.12 FLEX STATES
PATH: ACTUAL VALUES  STATUS  FLEX STATES
There are 256 FlexState
TM
bits available. The second line value indicates the state of the given FlexState bit.
6.2.13 ETHERNET
PATH: ACTUAL VALUES  STATUS  ETHERNET
These values indicate the status of the first, second, and third Ethernet links.
6.2.14 REAL TIME CLOCK SYNCHRONIZING
PATH: ACTUAL VALUES  STATUS  REAL TIME CLOCK SYNCHRONIZING
The RTC Sync Source actual value is the time synchronizing source the relay is using at present. Possible sources are:
Port 1 PTP Clock, Port 2 PTP Clock, Port 3 PTP Clock, IRIG-B, SNTP, and None. An actual value displays when the relay
includes the IEEE 1588 software option.
The Grandmaster ID is the grandmasterIdentity code being received from the present PTP grandmaster, if any. When the
relay is not using any PTP grandmaster, this actual value is zero. The grandmasterIdentity code is specified by PTP to be
globally unique, so one can always know which clock is grandmaster in a system with multiple grandmaster-capable clocks.
 FLEX STATES

PARAM 1: Off
Off
Range: Off, On
MESSAGE
PARAM 2: Off
Off
Range: Off, On
↓
MESSAGE
PARAM 256: Off
Off
Range: Off, On
 ETHERNET

ETHERNET PRI LINK
STATUS: Fail
Range: Fail, OK
MESSAGE
ETHERNET SEC LINK
STATUS: Fail
Range: Fail, OK
MESSAGE
ETHERNET TRD LINK
STATUS: Fail
Range: Fail, OK
 REAL TIME CLOCK
 SYNCHRONIZING
RTC Sync Source:
None
Range: See text below
MESSAGE
GrandMaster ID:
0X0000000000000000
Range: Any 8 octet value
MESSAGE
Accuracy:
999,999,999 ns
Range: 0 to 999, 999, 999 ns
MESSAGE
Port 1 PTP State:
NO SIGNAL
Range: Disabled, No Signal, Calibrating, Synch’d (No
Pdelay), Synchronized
MESSAGE
Port 2 PTP State:
NO SIGNAL
Range: Disabled, No Signal, Calibrating, Synch’d (No
Pdelay), Synchronized
MESSAGE
Port 3 PTP State:
NO SIGNAL
Range: Disabled, No Signal, Calibrating, Synch’d (No
Pdelay), Synchronized
MESSAGE
PTP - IRIG-B Delta:
500,000,000 ns
Range: -500,000,000 to +500,000,000 ns
