6 ACTUAL VALUES 6.2 STATUS
6
b) STATISTICS
PATH: ACTUAL VALUES  STATUS  REMOTE DEVICES STATISTICS  REMOTE DEVICE 1(16)
Statistical data (two types) for up to 16 programmed remote devices is shown here.
The STNUM number is obtained from the indicated remote device and increments whenever a change of state of at least
one item occurs in the GSSE/GOOSE message. The SQNUM number is obtained from the indicated remote device and
increments whenever a GSSE/GOOSE message, without a state change, is sent. When the GSSE/GOOSE message
trasmits a state change, the
SQNUM resets to 0. This number rolls over to zero when a count of 4,294,967,295 is incre-
mented.
6.2.10 DIGITAL COUNTERS
PATH: ACTUAL VALUES  STATUS  DIGITAL COUNTERS  DIGITAL COUNTERS Counter 1(8)
The present status of the eight digital counters is shown here. The status of each counter, with the user-defined counter
name, includes the accumulated and frozen counts (the count units label will also appear). Also included, is the date and
time stamp for the frozen count. The COUNTER 1 MICROS value refers to the microsecond portion of the time stamp.
6.2.11 SELECTOR SWITCHES
PATH: ACTUAL VALUES  STATUS  SELECTOR SWITCHES
The display shows both the current position and the full range. The current position only (an integer from 0 through 7) is the
actual value.
 REMOTE DEVICE 1

REMOTE DEVICE 1
StNum: 0
MESSAGE
REMOTE DEVICE 1
SqNum: 0
 DIGITAL COUNTERS
 Counter 1
Counter 1 ACCUM:
0
MESSAGE
Counter 1 FROZEN:
0
MESSAGE
Counter 1 FROZEN:
YYYY/MM/DD HH:MM:SS
MESSAGE
Counter 1 MICROS:
0
 SELECTOR SWITCHES

SELECTOR SWITCH 1
POSITION: 0/7
Range: Current Position / 7
MESSAGE
SELECTOR SWITCH 2
POSITION: 0/7
Range: Current Position / 7
