6-10 C60 Breaker Protection System GE Multilin
6.2 STATUS 6 ACTUAL VALUES
6
6.2.16 DIRECT DEVICES STATUS
PATH: ACTUAL VALUES  STATUS  DIRECT DEVICES STATUS
These actual values represent the state of direct devices 1 through 16.
6.2.17 IEC 61850 GOOSE INTEGERS
PATH: ACTUAL VALUES  STATUS  IEC 61850 GOOSE UINTEGERS
The C60 Breaker Protection System is provided with optional IEC 61850 communications capability. This
feature is specified as a software option at the time of ordering. See the Order Codes section in chapter 2
for details.
The IEC 61850 GGIO5 integer input data points are displayed in this menu. The GGIO5 integer data values are received
via IEC 61850 GOOSE messages sent from other devices.
6.2.18 EGD PROTOCOL STATUS
a) FAST EXCHANGE
PATH: ACTUAL VALUES  STATUS  EGD PROTOCOL STATUS  PRODUCER STATUS  FAST EXCHANGE 1
These values provide information that may be useful for debugging an EGD network. The EGD signature and packet size
for the fast EGD exchange is displayed.
 DIRECT DEVICES
 STATUS
DIRECT DEVICE 1
STATUS: Offline
Range: Offline, Online
MESSAGE
DIRECT DEVICE 2
STATUS: Offline
Range: Offline, Online
↓
MESSAGE
DIRECT DEVICE 16
STATUS: Offline
Range: Offline, Online
 IEC 61850
 GOOSE UINTEGERS
UINT INPUT 1
0
MESSAGE
UINT INPUT 2
0
↓
MESSAGE
UINT INPUT 16
0
 FAST EXCHANGE 1

FAST EXCHANGE 1
SIGNATURE: 0
MESSAGE
FAST EXCHANGE 1
DATA LENGTH: 0
