GE Multilin C60 Breaker Protection System A-13
APPENDIX A A.1 PARAMETER LISTS
A
A.1.2 FLEXINTEGER ITEMS
FlexInteger items are also viewable in a web browser. In the browser, enter the IP address of the UR, access the Device
Information Menu option, then the FlexInteger Parameter Listing option.
45632 GOOSE Analog In 25 --- IEC 61850 GOOSE analog input 25
45634 GOOSE Analog In 26 --- IEC 61850 GOOSE analog input 26
45636 GOOSE Analog In 27 --- IEC 61850 GOOSE analog input 27
45638 GOOSE Analog In 28 --- IEC 61850 GOOSE analog input 28
45640 GOOSE Analog In 29 --- IEC 61850 GOOSE analog input 29
45642 GOOSE Analog In 30 --- IEC 61850 GOOSE analog input 30
45644 GOOSE Analog In 31 --- IEC 61850 GOOSE analog input 31
45646 GOOSE Analog In 32 --- IEC 61850 GOOSE analog input 32
61439 PMU Num Triggers --- Phasor measurement unit recording number of triggers
Table A–2: FLEXINTEGER DATA ITEMS
ADDRESS FLEXINTEGER NAME UNITS DESCRIPTION
9881 PMU 1 SOC seconds PMU 1 SOC timestamps
9883 PMU 1 FRACSEC seconds PMU 1 FRACSEC timestamps
9885 PMU 1 STAT --- PMU 1 STAT flags
9887 PMU 2 SOC seconds PMU 2 SOC timestamps
9889 PMU 2 FRACSEC seconds PMU 2 FRACSEC timestamps
9891 PMU 2 STAT --- PMU 2 STAT flags
9968 GOOSE UInt Input 1 --- IEC61850 GOOSE UInteger input 1
9970 GOOSE UInt Input 2 --- IEC61850 GOOSE UInteger input 2
9972 GOOSE UInt Input 3 --- IEC61850 GOOSE UInteger input 3
9974 GOOSE UInt Input 4 --- IEC61850 GOOSE UInteger input 4
9976 GOOSE UInt Input 5 --- IEC61850 GOOSE UInteger input 5
9978 GOOSE UInt Input 6 --- IEC61850 GOOSE UInteger input 6
9980 GOOSE UInt Input 7 --- IEC61850 GOOSE UInteger input 7
9982 GOOSE UInt Input 8 --- IEC61850 GOOSE UInteger input 8
9984 GOOSE UInt Input 9 --- IEC61850 GOOSE UInteger input 9
9986 GOOSE UInt Input 10 --- IEC61850 GOOSE UInteger input 10
9988 GOOSE UInt Input 11 --- IEC61850 GOOSE UInteger input 11
9990 GOOSE UInt Input 12 --- IEC61850 GOOSE UInteger input 12
9992 GOOSE UInt Input 13 --- IEC61850 GOOSE UInteger input 13
9994 GOOSE UInt Input 14 --- IEC61850 GOOSE UInteger input 14
9996 GOOSE UInt Input 15 --- IEC61850 GOOSE UInteger input 15
9998 GOOSE UInt Input 16 --- IEC61850 GOOSE UInteger input 16
Table A–1: FLEXANALOG DATA ITEMS (Sheet 13 of 13)
ADDRESS FLEXANALOG NAME UNITS DESCRIPTION
