ECG/
Pace
■ Display Lead: Top or first lead
displayed on the bedside and
graphed with alarms and
manual prints.
• To Change the Display Lead:
– Select ECG.
– Select DISPLAY LEAD II.
– A popup menu opens.
– Move the cursor in front of
the desired display lead and
press to select.
– Select MAIN MENU to
exit.
■ Size: Changes the size of all
ECG waveforms displayed and
graphed. 1X is the standard
size.
NOTE: At least a 0.5 millivolt QRS complex at standard size is
needed for beat detection.
• To Adjust ECG Size:
– Select ECG.
– Select ECG SIZE.
– Turn the Trim Knob to
highlight desired selection
and press to select.
– Select MAIN MENU to
exit.
