■ BP Waveform:
• To Graph Waveforms
(without ECG lead):
– Select MORE MENUS.
– Select MONITOR SETUP.
– Select GRAPH SETUP.
– Select GRAPH BP
INVASIVE.
– Highlight desired
waveforms to be graphed.
– Highlight GRAPH.
– Select MAIN MENU to
exit.
– Press the GRAPH GO/
STOP button on the
monitor to stop the graph.
NOTE: This option is also available in the PA Insert/Wedge
menu.
■ Graph Location:
• To Change the Graph
Locations:
– Select MORE MENUS.
– Select MONITOR SETUP.
– Select GRAPH SETUP.
– Select GRAPH
LOCATION.
– Select MANUAL, ALARM
or PRINT WINDOW
GRAPH LOCATION.
An information window is
displayed with a list of
available writers.
– Turn Trim Knob to move
the cursor to select the
specific writer and press to
select.
– Select MAIN MENU to
exit.
