DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
Chapter 4 Functional Checks 4 - 17
Probe/Connectors Checks
NOTE: Probes can be connected at any time, whether the LOGIQ E10 is ON or OFF.
To connect a probe
1.) Place the probe's carrying case on a stable surface and open the case.
2.) Carefully remove the probe and unwrap the probe cable.
3.) DO NOT allow the probe head to hang free. Impact to the probe head could result in irreparable
damage.
4.) Turn the connector locking handle counterclockwise.
5.) Align the connector with the probe port and carefully push into place.
6.) Turn the connector locking handle clockwise to secure the probe connector.
7.) Carefully position the probe cable in the probe cord holder spot so it is free to move, but not
resting on the floor.
Probes Requiring a Leakage Test
If the probe requires a Leakage Test, see: Section 10-7 "Electrical Safety Tests" on page 10-12.
CAUTION
TAKE THE FOLLOWING PRECAUTIONS WITH THE PROBE CABLES:
- KEEP AWAY FROM THE WHEELS
- DO NOT BEND
- DO NOT CROSS CABLES BETWEEN PROBES
Table 4-7 Probe and Connectors Checks
Step Task Expected Result(s)
1.
Select the appropriate connected probe
from the probe indicators on the Touch
Panel.
The probe activates in the currently-selected
operating mode. The probe's default settings
for the mode and selected exam are used
automatically.
2.
Launch the application.
To change application without changing the
current probe, press THE DESIRED MODE
on the Operator Panel.
The selected application starts.
3.
Verify no missing channels All channels is functioning.
4.
Verify there's no EMI/RFI or artifacts specific
to the probe.
No EMI/RFI or artifacts.
5.
Test the probe in each active connector slot.,
see: Section 3-4-6 "Connecting Probes" on
page 3-19.
It will display pictorial data each time
6.
Repeat this procedure for all available probes.
