8 - 326 Section 8-11 - Front End Acquisition / Card Cage parts replacement
ECG
LOGIQ E10 Basic Service Manual, Direction
5750007-1EN, Rev. 1. Leakage Current
measured at (record the value) and meets
allowable limits. Equipment passed all required
checks and is ready for use.
4-2-7 Probe/Connectors Checks
4-2-7
PW/CW Doppler Mode Checks
use pencil probes
10-7-7
Isolated patient lead (source) leakage-
lead to ground
10-7-8
Isolated patient lead (source) leakage–
lead to lead
10-7-9
Isolated patient lead (sink) leakage-
isolation test
4-2-7
ECG Checks
Active ECG:
Utility -> Applications ->
Settings -> ECG -> Show ECG Tools.
Connect cables. Press Display ECG Tab
on TP. Verify ECG signal displayed on
monitor.
Plug in the ECG cables with nothing
attached so they pick up noise.
Diagnostics
Diagnostics
4-2-7
Shear Wave Elastography (Shear Elasto)
Functional Checks
Power Assistant
4-2-7 Probe/Connectors Checks
Verify Power Assistant Option functions
Shear Wave
4-2-7 Probe/Connectors Checks
4-2-7
Shear Wave Elastography (Shear Elasto)
Functional Checks
Perform a 4D sweep, if 4D MC was
removed.
V Nav
4-2-7 Probe/Connectors Checks
4-2-7
3D/4D and Volume Navigation Functional
Checks
4-2-7 Basic Measurements
Table 8-335 Connector Panel replacement Functional Checks
See:
Section
Functional Check Debrief Script
