Troubleshooting: CPU PCB Input/Output Signals
MAC 5000 resting ECG analysis system
2000657-002
LCD (J10)
Pin No. Signal
1 Ground
2Pixel Clock
3 Hsync
4Vsync
5 Ground
6 R0 (LSB)
7 R1
8R2
9 R3
10 R4
11 R5 (MSB)
12 Ground
13 G0 (LSB)
14 G1
15 G2
16 G3
17 G4
18 G5 (MSB)
19 Ground
20 B0 (LSB)
21 B1
22 B2
23 B3
24 B4
25 B5 (MSB)
26 Ground
27 Data Enable
28 3V Power
29 3V Power
30 NC
31 NC
