Revision B6-4
Parts Lists and Drawings: Field Replaceable Units
MAC 5000 resting ECG analysis system
2000657-002
Field Replaceable Units
The following items may not be assigned separate manufacturing part
numbers because they are normally part of a larger assembly. Since they
are considered field replaceable units (FRUs), they have specific service
part numbers so they can be ordered and replaced by service
technicians. Contact Tech Support for FRU information for assemblies
used on previous configurations.
* Replacement of these assemblies requires complete disassembly of the
unit and should only be performed by a qualified service person. Return
to factory, 48 hour turnaround, service is available for this product.
NOTE
Verify part numbers before ordering service
parts (field replaceable units). See the tech
memo series for this product for changes or
additions to this list.
Table 6-1. Field Replaceable Units
Item Part Number
Battery Assembly 900770-001
Power Supply Assembly 421117-001
PCB, MAC 5000 CPU* 801212-003
Keyboard Assembly, English* 421115-001
Disk Drive, 3.5 inch Laptop Floppy* 2001377-001
Display Assembly* 421114-002
Printhead 422397-001
Writer Assembly 421108-003
Roller Assembly 422396-002
