GE NX-4-EUR User Manual

PROGRAMMING THE NX-4 KEYPADS
Programming the LED keypads
This section describes how to program the address and partition for each keypad, and it also
explains the options that are available. The address of the keypad is important because the
panel uses it to supervise the keypads.
The factory default for the master code is [1]-[2]-[3]-[4] when using a 4-digit code, or [1]-[2]-
[3]-[4]-[5]-[6] for a 6-digit code. The factory default for the “Go To Program” code is [9]-[7]-[1]-
[3] for a 4-digit code, or [9]-[7]-[1]-[3]-[0]-[0] for a 6-digit code.
[*]-[9]-[3] SET KEYPAD OPTIONS
1. Enter [*]-[9]-[3] [program code]- the “Service” LED will flash.
2. LED’s 1-8 can now be toggled on/off to enable/disable the following functions:
3. After enabling/disabling the desired functions press [*]
LED Keypad feature enabled
1
Box tamper on
2
Enable silent keypad option (no entry/exit delay sounder, no chime)
3
Enable Ding Dong sound for chime - If this is off, the chime will be a single tone
(see location 40).
4
Enable keypress silence option
(Silences the pulsing keypad sounder for 5 seconds when a key is pressed).
5
Enable armed status suppression
(Will not allow the keypad to display faulted or bypassed zones when the system is
armed).
6
Enable panic, fire, medical beep tone
(Will sound a short beep to verify that the keypress has been accepted).
7
Suppresses the “Service” LED
(Will not allow the “Service” LED to light up for any reason. If there is a system
malfunction (trouble), pressing [*]-[2] will still display the service menu.)
8
Enable multi-partition viewing
(Enables temporary viewing of all partitions, by pressing [*]-[1]-[partition number]).
