APPENDIX 3: EXPANDER NUMBERS FOR REPORTING
EXPANDER TROUBLE
The tables below list the device numbers that will be reported for each expander/keypad where a trouble condition
is present. For trouble conditions relating to the control panel, the device number is “0”.
Keypads
KEYPAD PART 1
1 192
2 200
3 208
4 216
5 224
6 232
7 240
8 248
Wireless receiver NX-448E
Wireless receiver DIP 1 DIP 2 DIP 3 Expander number reported
1 OFF 35 OFF OFF
2 ON OFF OFF 36
3 OFF ON OFF 37
4 ON ON OFF 38
5 OFF OFF ON 39
6 ON OFF ON 32
7 OFF ON ON 33
8 ON ON ON 34
Output module NX-507E or NX-508E
Output module DIP 1 DIP 2 DIP 3 Expander number reported
1 ON ON OFF 24
2 OFF OFF ON 25
3 ON OFF ON 26
4 OFF ON ON 27
5 ON 28 ON ON
6 OFF OFF OFF 29
7 ON OFF OFF 30
8 OFF ON OFF 31
NX-4-EUR Installation manual Page 91 02/07/06
