GE NX-4-EUR User Manual

NX-4 WIRING DIAGRAM
Z1
Z2
Z3
Z4
COM COM SIREN
Z
O
N
E
S
AUX2
SMOKE+
AC AC
T1 T R R1
POS (Aux Pwr +) COM (Aux Pwr -)
DATA
EARTH
LIGHTNING PROTECTION THE CONTROL PANEL MUST BE EARTH GROUNDED FOR LIGHTNING PROTECTION TO WORK EFFECTIVELY.
CE APPROVED TRANSFORMER 16.5Vac / 35VA
DO NOT CONNECT 230VAC TO TERMINAL STRIP.
230V AC 50Hz PRIMARY FUSE : 500mA
+10%/-15%
+
BUILT IN SIREN DRIVER FOR 15 OR 30 WATT SPEAKERS 4,8 OR 16 OHM LOAD.
MAX TOTAL WIRE RUN IS 800m. MAX NUMBER OF DEVICES IS 8 KEYPADS AND 1 OTHER DEVICE.
SMOKE+ TERMINAL IS CURRENT LIMITED TO 250 mA. KEYPAD + TERMINAL IS LIMITED TO 1 AMP.
THE TOTAL STANDBY CURRENT DRAWN FROM TERMINALS SMOKE+, KEYPAD POS AND AUX PRW+, WHEN ADDED TOGETHER, MUST NOT EXCEED. 1A WITH A 35VA TRANSFORMER.
1 NORMALLY OPEN CONTACT AND 1 NORMALLY CLOSED CONTACT WITH E.O.L. RESISTOR
3.3K E.O.L.
ANY ZONE TERMINAL
ANY COM TERMINAL
NORMALLY CLOSED CONTACT WITH E.O.L. RESISTOR
3.3K E.O.L.
ANY ZONE TERMINAL
ANY COM TERMINAL
ANY ZONE TERMINAL
NORMALLY OPEN CONTACT WITH E.O.L. RESISTOR
3.3K E.O.L.
ANY COM TERMINAL
DOUBLED ZONE CONFIGURATION USED AS A FIRE ZONE
3.74K E.O.L.
ANY ZONE TERMINAL
ANY COM TERMINAL
ANY COM TERMINAL
DOUBLED ZONE CONFIGURATION. THE 3.74K RESISTOR IS FOR ZONES 1 - 4 THE 6.98K RESISTOR IS FOR ZONES 5 - 8
6.98K E.O.L. (5-8)
ANY ZONE TERMINAL
3.74K E.O.L. (1 - 4)
*** IF A DOUBLED ZONE IS USED AS A FIRE ZONE THE HIGH ZONE (5 - 8) IS NOT USABLE.
EUROPEAN 1E.O.L./ 2E.O.L. ZONE DOUBLING ZONES 5 - 8.
BLUE WHT GRAY BRN
6.98K
BRN
ZONE DOUBLING ZONES 1- 4.
ORG VIOLET YEL BRN
3.74K
BRN
E.O.L RESISTORS
2 NORMALLY OPEN CONTACT AND 2 NORMALLY CLOSED CONTACT WITH E.O.L. RESISTOR
3.3K E.O.L.
ANY ZONE TERMINAL
ANY COM TERMINAL
EUROPEAN DOUBLE E.O.L. CONFIGURATION
ANY ZONE TERMINAL
ANY COM TERMINAL
3.3K E.O.L.
3.3K E.O.L.
TAMPER CONTACT
FOR VOLTAGE OUTPUT PROGRAM LOCATION 37, SEGMENT 2, FEATURE 1.
(Supervised)
4 WIRE SMOKE DETECTOR
MAX 8 KEYPADS AND
2 OTHER DEVICES
NX-108E NX-116E NX-124E
NX-148E
NX-1308E NX-1316E
NX-1324E
NX-1508E
NX1516E
NX-1348E-ICON
N
ETWORX KEYPAD PART #
NX-1208E NX-1248E
IF BOX TAMPER IS ENABLED IN LOCATION 37, CONNECT A NORMALLY CLOSED SWITCH TO THESE PINS.
R
E
D
B
L
A
C
K
-
PROGRAM
Pin 1
NetworX Bu
s
THESE LEDs ARE FOR PROPER CIRCUIT OPERATION ONLY.
TO PREVENT RISK OF ELECTRICAL SHOCK, ALWAYS DISCONNECT THE TELEPHONE LINE PRIOR TO SERVICING.
WARNING
AU
DIO TAP
Pin 1
ALL ZONE INPUTS ARE SUPERVI
SED.
COM
AUX 1
(S
upervised)
NX-4-EUR Installation manual Page 84 02/07/06
