ALPHANUMERIC CHARACTER TABEL
1 A 20 T 39 ä 58 n 77 #
2 B 21 U 40 ä 59 o 78 $
3 C 22 V 41 b 60 ô 79 &
4 D 23 W 42 c 61 ö 80 '
5 E 24 X 43 ç 62 p 81 (
6 F 25 Y 44 d 63 q 82 )
7 G 26 Z 45 e 64 r 83 *
8 H 27 0 46 é 65 s 84 +
9 I 28 1 47 è 66 t 85 ,
10 J 29 2 48 ê 67 u 86 -
11 K 30 3 49 f 68 û 87 .
12 L 31 4 50 g 69 ü 88 /
13 M 32 5 51 h 70 v 89 :
14 N 33 6 52 i 71 w 90 ;
15 O 34 7 53 î 72 x 91 <
16 P 35 8 54 j 73 y 92 =
17 Q 36 9 55 k 74 z 93 >
18 R 37 a 56 l 75 ! 94 .
19 S 38 à 57 m 76 ” 95 °
EXITING THE PROGRAM MODE
When you have made all the desired changes in programming, it is time to exit the program
mode. Press the [Exit] key to exit this programming level, and go to the “Select a Module To
Program” level. If no additional modules are to be programmed, press the [Exit] key again to
exit the program mode. If there is a module to be programmed, you can select it by entering
its address, followed by the [#] key (see “Selecting the Module To Program” above). The
procedure for programming these devices is the same as for the control panel, except that the
locations will be for the module selected.
Note: the timeout for the program mode is 15 minutes.
LOADING FACTORY DEFAULTS
To load the factory defaults, enter the program mode using the above procedure, then type
[9]-[1]-[0]-[#]. The keypad will beep 3 times to show that loading is in progress. The loading
takes about 6 seconds.
ENROLLING MODULES AND KEYPADS
For supervision purposes, the presence of all keypads, zone expanders, wireless receivers, and
any other modules connected to the data terminal can automatically be found and stored in
the NX-4’s memory. This allows the control panel to supervise these modules. Note: All
modules should be connected and set to unique addresses before modules are enrolled. To
enroll the modules, enter the program mode of the NX-4 control panel as described above. If
necessary, go on to program the rest of the control panel and devices. When you exit from
program mode, the control panel will automatically enroll the devices. The enrolling process
takes about 12 seconds, during this time the “Service Screen” will be displayed. If a module
has been enrolled but it is not detected by the control, the “Service Screen” will be displayed.
NX-4-EUR Installation manual Page 32 02/07/06
