4 Command and Query Summary
K0472 Revision A 4-6
:CAL:PRES:VAL
Applicability: PACE1000, PACE5000, PACE6000
Command Syntax
:CALibration[x]:[PRESsure]:VALue[y]
where: x (module) = 1 or 2 (default - 1). y = 1, 2 or 3 (pressure point) (default - 1).
Parameter: <decimal>
Short form: :CAL[x]:VAL[y]
Function: Enables calibration value to be entered.
Defaults:
Query Syntax
:CALibration[x]:[PRESsure]:VALue[y]?
where: x (module) = 1 or 2 (default - 1). y = 1, 2 or 3 (pressure point) (default - 1).
Short form: :CAL[x]:VAL[y]?
Function: Queries calibration point y value of module x.
Response: Returns pressure value for VALue[y] of module [x].
Description
Valid only when calibration is enabled. This command enables a calibration value to be
entered during the calibration process. The query gets the calibration value.
Example for a 2 bar unit
Tx CAL:PRES:VAL1?
Rx CAL:PRES:VAL1 -0.9
Tx CAL:PRES:VAL2?
Rx CAL:PRES:VAL2 0
Tx CAL:PRES:VAL3?
Rx CAL:PRES:VAL3 2.0
y 3 Calibration points
1 lower pressure
2 middle pressure
3 higher pressure
