4 Command and Query Summary
K0472 Revision A 4-64
:SENS:PRES:FILT:LPAS:BAND
Applicability: PACE1000, PACE5000, PACE6000
Command Syntax
:SENSe[x][:PRESsure]:FILTer:[LPASs]:BAND <number>
where x = 1 or 2 is the module number
(default - 1)
Parameter: <decimal> filter band response value in % full-scale.
Short form: :SENS:FILT:BAND
Function: Used to set-up the response band component of the filter.
Default: 0
minimum 0
maximum 100.0
Query Syntax
:SENSe[x][:PRESsure]:FILTer:[LPASs]:BAND?
where x = 1 or 2 is the module number
(default - 1)
Short form: :SENS:FILT:BAND?
Function: Ask for filter step response band parameter.
Response: Number corresponding to filter step response value in % full-scale.
Description
The digital low pass filter has a response band configured as percentage of full-scale.
e.g., defaults to 0.05 %FS. If the reading has changed by more than the configured band
response value then the filtering is ignored for that conversion and the pressure goes
instantly to the new value.
Example
:SENS:PRES:FILT:LPAS:BAND
TX> :SENS:PRES:FILT:LPAS:BAND?
RX> :SENS:PRES:FILT:LPAS:BAND 50.0000000
The current setting for the filter band is 50% of full-scale, i.e., the filter applies only when the
change of pressure is within this band.
It can be changed to another number, (for example: 12% of full-scale), by sending:
TX> :SENS:PRES:FILT:LPAS:BAND 12
TX> :SENS:PRES:FILT:LPAS:BAND?
RX> :SENS:PRES:FILT:LPAS:BAND 12.0000000
