APPENDIX D IEC 60870-5-104 COMMUNICATIONSD.1IEC 60870-5-104 PROTOCOL D.1.1 INTEROPERABILITY
This document is adapted from the IEC 60870-5-104 standard. For this section the boxes indicate the following:  – used
in standard direction;  – not used;  – cannot be selected in IEC 60870-5-104 standard.
1. SYSTEM OR DEVICE:
 System Definition
 Controlling Station Definition (Master)
 Controlled Station Definition (Slave)
2. NETWORK CONFIGURATION:
 Point-to-Point  Multipoint
 Multiple Point-to-Point  Multipoint Star
3. PHYSICAL LAYER
Transmission Speed (control direction):
Transmission Speed (monitor direction):
4. LINK LAYER
Unbalanced Interchange
Circuit V.24/V.28 Standard:
Unbalanced Interchange
Circuit V.24/V.28 Recommended
if >1200 bits/s:
Balanced Interchange Circuit
X.24/X.27:
 100 bits/sec.
 200 bits/sec.
 300 bits/sec.
 600 bits/sec.
 1200 bits/sec.
 2400 bits/sec.
 4800 bits/sec.
 9600 bits/sec.
 2400 bits/sec.
 4800 bits/sec.
 9600 bits/sec.
 19200 bits/sec.
 38400 bits/sec.
 56000 bits/sec.
 64000 bits/sec.
Unbalanced Interchange
Circuit V.24/V.28 Standard:
Unbalanced Interchange
Circuit V.24/V.28 Recommended
if >1200 bits/s:
Balanced Interchange Circuit
X.24/X.27:
 100 bits/sec.
 200 bits/sec.
 300 bits/sec.
 600 bits/sec.
 1200 bits/sec.
 2400 bits/sec.
 4800 bits/sec.
 9600 bits/sec.
 2400 bits/sec.
 4800 bits/sec.
 9600 bits/sec.
 19200 bits/sec.
 38400 bits/sec.
 56000 bits/sec.
 64000 bits/sec.
Link Transmission Procedure: Address Field of the Link:
 Balanced Transmission
 Unbalanced Transmission
 Not Present (Balanced Transmission Only)
 One Octet
 Two Octets
 Structured
 Unstructured
Frame Length (maximum length, number of octets): Not selectable in companion IEC 60870-5-104 standard
