GE Multilin T35 Transformer Protection System D-9
APPENDIX D D.1 IEC 60870-5-104 PROTOCOL
D
Maximum range of values k: 1 to 32767 (2
15
– 1) APDUs, accuracy 1 APDU
Maximum range of values w: 1 to 32767 APDUs, accuracy 1 APDU
Recommendation: w should not exceed two-thirds of k.
Portnumber:
RFC 2200 suite:
RFC 2200 is an official Internet Standard which describes the state of standardization of protocols used in the Internet
as determined by the Internet Architecture Board (IAB). It offers a broad spectrum of actual standards used in the Inter-
net. The suitable selection of documents from RFC 2200 defined in this standard for given projects has to be chosen
by the user of this standard.
 Ethernet 802.3
 Serial X.21 interface
 Other selection(s) from RFC 2200 (list below if selected)
D.1.2 POINT LIST
The IEC 60870-5-104 data points are configured through the
SETTINGS  PRODUCT SETUP  COMMUNICATIONS  DNP /
IEC104 POINT LISTS menu. Refer to the Communications section of Chapter 5 for additional details.
PARAMETER VALUE REMARKS
Portnumber 2404 In all cases
