Replacement Procedures
8-94 Vivid E80/E90/E95 – Service Manual
GC091052
Rev. 3
Preparations
When preparing for the replacement, you must perform the
following steps:
1. Power down the Ultrasound system.
2. Disconnect the Mains Power Cable from the wall outlet.
3. Disconnect all probes and external I/O cabling.
4. Remove the Right Side Cover.
5. Remove the FEP Cover.
6. Remove the Front Plane boards.
Remove the CRX board
Follow these steps to remove the CRX board:
1. Pull out the CRX board.
2. Place it on an ESD safe place.
Install the CRX board
Follow these steps to install the CRX board:
1. Carefully align the CRX board with the rails and push it in till
it is seated in the Back Plane connectors.
2. Install the FEP Cover.
3. Install the Right Side Cover.
WARNING
Prior to removing the Card Rack boards, the LEDs on the end
of each board should be unlit, to indicate boards are
unpowered.

GE Vivid E95 Specifications

General

Type	Cardiovascular Ultrasound System
Transducers	2D, 3D, 4D
Display	22-inch high-resolution OLED monitor
Portability	Cart-based
Imaging Modes	2D, 3D, 4D, Color Doppler
Advanced Features	cSound Architecture
Connectivity	DICOM, USB, Ethernet
Applications	Cardiology, Vascular, Abdominal
