gefran ADV200 SP Series User Manual

72 ADV200 SP • Quick start up guide - Specification and installation
9.5 Input electrical data
9.5.1 AC power supply
AC Input voltage, Uln �������������������������� 3 ph 380Vac -15% ... 480Vac +10%
Types of networks ____________________________ IT, TN and TT (with the possible adoption of EMI filters external to the drive)
AC Input frequency ��������������������������� 50/60 Hz, ± 5%
Choke �������������������������������������� integrated (DC)
Total harmonic distortion (THD) ����������������� 40% Light duty, 50% Heavy duty (at nominal current)
Sizes
ADV200
ADV200 SP-...-4 versions (Motor cos phi 0.9 @ 400
VAc)
AC Input current
Heavy duty (Arms) Light duty (Arms)
1015 2.1 3.7
1022 3.7 4.9
1030 4.9 6.5
1040 6.5 8.1
1055 8.1 11.1
2075 11.1 14.0
2110 14.0 19.6
2150 19.6 26.4
3185 26.4 32.3
3220 32.3 39
3300 39 53
4370 53 64
4450 64 74
4550 74 89
5750 100 143
5900 143 171
51100 171 200
61320 200 238
61600 238 285
9.5.2 DC power supply
DC voltage supply (from photovoltaic panels) �������� 350Vdc - 750Vdc operational, 800Vdc maximum (only configurations where the
positive and negative poles of the PV panels are insulated from the ground are
allowed).
Sizes
ADV200 sp
ADV200 SP-...-4 versions (Motor cos phi 0.9 @ 400
VAc)
DC Input current
Heavy duty (Arms) Light duty (Arms)
1015
3 4.7
1022
5 6.2
1030
6 8.1
1040
8 10
1055
10 14
2075
14 18
2110
18 25
2150
25 33
3185
33 40
3220
39 48
3300
48 65
4370
65 80
4450
80 90
4550
90 125
5750
125 175
5900
175 210
51100
210 240
61320
240 290
61600
290 350
