—————— Instruction manual ——————
137
Explanation of parameter tables
Inthefollowingpagestheparameterslistofeachmenuisshown.Foreachtablethefollowingnotesarevalid:
“No.”column Parameternumber(decimal).Inordertoaddressparameterswhenaserialline/busor
theAPC300cardareused,theusermust add2000H(=decimal8192)totheindicated
value.
“Value”eld S=valuedependingonthesizeofthedevice.
DRIVE STATUS
Startupparametersstatus
START UP
Basiccommissioningofthedrive
TUNING
Driveregulatorstuning
MONITOR
Displayofreferencevalues,speeed,voltage,current,frequency...
INPUT VARIABLES
Rampreference,speedreference,currentreference
LIMITS
Speedlimits,currentlimits,eldcurrentlimits
RAMP
Acceleration,deceleration,quickstop,rampshape
SPEED REGULAT
Congurationofthespeedregulator,speedzerologic,speedup,droopfunction
CURRENT REGULAT
Congurationofthecurrentregulator
FLUX REGULATION
Functioningoftheeldcurrentregulator
REG PARAMETERS
Parametersforspeed,current,eldandvoltageregulation
CONFIGURATION
Functioning,regulation,encodertype,functionfactor,programmablealarms,address,
password
I/O CONFIG
Congurationofprogrammabledigitalandanaloginputandoutput
ADD SPEED FUNCT
Motorcapture,adaptivespeedregulation,speedcontrol,speedzero
FUNCTIONS
Motopotentiometer,jogfunction,multi-speed,multi-ramps,overload,stopcontrol,Taper
currentfunction
SPEC FUNCTIONS
Testgenerator,savingparameters,loadingfactorysettings,signaladaptation,PADparam-
eters
OPTIONS
Accesstotheoptionaleldbuscard(Option1),andtheAPC300(Option2),PIDfunction
DRIVECOM
ParametersettingfortheDRIVECOMprole
SERVICE
Menu,onlyaccessibletoservicepersonnelofthemanufacturer
