gefran TPD32-EV-500 series User Manual

—————— TPD32-EV ——————
98
note!  Tables4.10.1-2-3-4showthemainschokeelectricalratings,butnottherelativecodes.Please
contactoursalesnetworkforfurtherdetails.
Table 4.10.5 Internal code for mains chokes
TPD32 EV
Standard sizes
Three-phase mains choke
Choke
rating
[mH]
Current
rating
[A]
Saturation
current
[A]
Frequency
[Hz]
Inductance type Code
Dimensions:
W x H x d
[mm]
Weight
[kg]
Mains voltage 400-460 V, 3Ph, 50 Hz
TPD32-EV-.../...-20-..-A 1,71 17,2 34,4 50 LR3-011 S7FF6 180 x 182 x 130 8
TPD32-EV-.../...-40-..-A 0,855 34,4 68,8 50 LR3-41-61-0,68 S7D03 190 x 170 x 150 10
TPD32-EV-.../...-70-..-A 0,488 60,2 120,4 50 LR3-61-91-0,45 S7D04 190 x 170 x 165 13
TPD32-EV-.../...-110-..-A 0,311 94,6 189,2 50 LR3-90-135-0,30 S7D05 240 x 210 x 180 20
TPD32-EV-.../...-140-..-A 0,244 120,4 240,8 50 LR3-107-160-0,26 S7D06 240 x 210 x 180 21
TPD32-EV-.../...-185-..-A 0,185 159 318 50 LR3-163-244-0,17 S7D07 240 x 235 x 210 29
TPD32-EV-.../...-280-..-B 0,122 241 482 50 LR3-253-380-0,11 S7D09 336 x 345 x 260 48
TPD32-EV-.../...-350-..-B 0,098 301 602 50 LR3-287-430-0,1 S7D10 336 x 355 x 270 59
TPD32-EV-.../...-420-..-B 0,081 361 722 50 LR3-368-552-0,076 S7D11 336 x 385 x 270 65
TPD32-EV-.../...-500-..-B 0,068 430 860 50 LR3-458-687-0,06 S7D12 375 x 420 x 305 80
TPD32-EV-.../...-650-..-B 0,053 559 1118 50 LR3-605-910-0,05 S7D27 375 x 525 x 305 110
TPD32-EV-.../...-770-.. -C 0,044 662 1324 50 LR3-685-1027-0,04 S7D14 450 x 453 x 305 105
TPD32-EV-.../...-1000-.. -C 0,034 860 1720 50 LR3-869-1303-0,03 S7D15 480 x 535 x 305 125
TPD32-EV-.../...-1050-.. -C 0,033 903 1806 50 LR3-869-1303-0,03 S7D15 480 x 535 x 305 125
Mains voltage 400-500 V, 3Ph, 60 Hz
TPD32-EV-.../...-17-..-A-NA 1,71 17.2 34.4 50 / 60 LR3-011 S7FF6 180 x 182 x 130 8
TPD32-EV-.../...-35-..-A-NA 0,855 34.4 68.8 50 / 60 LR3-41-61-0,68 S7D03 190 x 170 x 150 10
TPD32-EV-.../...-56-..-A-NA 0,488 60.2 120.4 50 / 60 LR3-61-91-0,45 S7D04 190 x 170 x 165 13
TPD32-EV-.../...-88-..-A-NA 0,311 94.6 189.2 50 / 60 LR3-90-135-0,30 S7D05 240 x 210 x 180 20
TPD32-EV-.../...-112-..-A-NA 0,244 120.4 240.8 50 / 60 LR3-107-160-0,26 S7D06 240 x 210 x 180 21
TPD32-EV-.../...-148-..-A-NA 0,185 159 318 50 / 60 LR3-163-244-0,17 S7D07 240 x 235 x 210 29
TPD32-EV-.../...-224-..-B-NA 0,122 241 482 50 / 60 LR3-253-380-0,11 S7D09 336 x 345 x 260 48
TPD32-EV-.../...-280-..-B-NA 0,098 301 602 50 / 60 LR3-287-430-0,1 S7D10 336 x 355 x 270 59
TPD32-EV-.../...-336-..-B-NA 0,081 361 722 50 / 60 LR3-368-552-0,076 S7D11 336 x 385 x 270 65
TPD32-EV-.../...-400-..-B-NA 0,068 430 860 50 / 60 LR3-458-687-0,06 S7D12 375 x 420 x 305 80
TPD32-EV-.../...-450-..-B-NA 0,053 559 1118 50 / 60 LR3-605-910-0,05 S7D27 375 x 525 x 305 110
TPD32-EV-.../...-560-..-C-NA 0,044 662 1324 50 / 60 LR3-685-1027-0,04 S7D14 450 x 453 x 305 105
TPD32-EV-.../...-800-..-C-NA 0,034 860 1720 50 / 60 LR3-869-1303-0,03 S7D15 480 x 535 x 305 125
TPD32-EV-.../...-850-..-C-NA 0,033 903 1806 50 / 60 LR3-869-1303-0,03 S7D15 480 x 535 x 305 125
note!  Thelineinductancefortheeldcircuitisusuallynotusedbecausethemotoreldloadalready
hasaveryhighinductivevaluewhichlimitsthenegativeeffectsoftransmissions.
Ifinductancehastobeused,youcancalculateitsvaluewiththefollowingsimpliedformula.
CurrentforthermaldimensioningisgivenbyIdn*ff.Seeparagraph4.10.1fordetails.
 Ldf=(Ukd*Uln)/(Idn*ff*2π*fn)[H]
Where:
 Ukdisthevoltagedrop(typically2%or4%)
 Ulnisthesupplyvoltage
 Idnistheeldcircuitcurrent
 ffistheformfactor(typically1.2)
 fnisthesupplyfrequency
 Theresultingvalueistotalinductance,whichisdividedequallyinthetwosupplyphases.
note!  TPD32-EV-FC-...:referenceshouldbemadetothecorrespondingvoltageandcurrentsizes
ofTPD32EVStandardsizes.
