gefran TPD32-EV-500 series User Manual

—————— TPD32-EV ——————
96
TPD32 EV
Standard sizes
Converter rated current
Rated inductance with
Ukd = 2%
Rated inductance with
Ukd = 4%
Rated current inductance
[A] [µH] [µH] [A]
TPD32-EV-500/...-2000-…-E 2000 11.3 22.5 1722
TPD32-EV-500/...-2400-…-E 2400 9.4 18.8 2066
TPD32-EV-500/...-2700-…-E 2700 8.3 16.7 2325
TPD32-EV-500/...-2900-…-E 2900 7.8 15.5 2497
TPD32-EV-500/...-3300-…-E 3300 6.8 13.6 2841
Mains voltage 500V, 3ph, 60 Hz
TPD32-EV-500/...-20-…-A 20 937.8 1875.7 17
TPD32-EV-500/...-40-…-A 40 468.9 937.8 34
TPD32-EV-500/...-70-…-A 70 268.0 535.9 60
TPD32-EV-500/...-110-…-A 110 170.5 341.0 95
TPD32-EV-500/...-140-…-A 140 134.0 268.0 121
TPD32-EV-500/...-185-…-A 185 101.4 202.8 159
TPD32-500/…-280-…-B 280 67.0 134.0 241
TPD32-500/…-350-…-B 350 53.6 107.2 301
TPD32-500/…-420-…-B 420 44.7 89.3 362
TPD32-500/…-500-…-B 500 37.5 75.0 431
TPD32-500/…-650-…-B 650 28.9 57.7 560
TPD32-EV-500/...-770-…-C 770 24.4 48.7 663
TPD32-EV-500/...-1000-…-C 1000 18.8 37.5 861
TPD32-EV-500/...-1050-…-C 1050 17.9 35.7 904
TPD32-EV-500/...-1400-...-D 1400 13.4 26.8 1205
TPD32-EV-500/...-1600-...-D 1600 11.7 23.4 1378
TPD32-EV-500/...-2000-...-D 2000 9.4 18.8 1722
TPD32-EV-500/...-2400-...-D 2400 7.8 15.6 2066
TPD32-EV-500/...-1200-…-E 1200 15.6 31.3 1033
TPD32-EV-500/...-1500-…-E 1500 12.5 25.0 1292
TPD32-EV-500/...-1700-…-E 1700 11.0 22.1 1464
TPD32-EV-500/...-1800-…-E 1800 10.4 20.8 1550
TPD32-EV-500/...-2000-…-E 2000 9.4 18.8 1722
TPD32-EV-500/...-2400-…-E 2400 7.8 15.6 2066
TPD32-EV-500/...-2700-…-E 2700 6.9 13.9 2325
TPD32-EV-500/...-2900-…-E 2900 6.5 12.9 2497
TPD32-EV-500/...-3300-…-E 3300 5.7 11.4 2841
• For575VtypeBTPD32convertersand575/690VtypeCconverters,whichareusuallyinstalledina
second-typeenvironment:inthiscaseUKDvaluesofaround2%canbeused,withtheadvantagethat
smallerreactorsarerequired.Otherwise,ifUKDmustbe=4%,alwayscomplywiththevaluesshownin
therelativecolumns.
Table 4.10.3: Mains chokes for 575 Vac input supply
TPD32 EV
Standard sizes
Converter rated current
Rated inductance with
Ukd = 2%
Rated inductance with
Ukd = 4%
Rated current inductance
[A] [µH] [µH] [A]
Mains voltage 575V, 3ph, 50 Hz
TPD32-EV-575/...-280-..-B 280 92.4 (*) 184.9 241
TPD32-EV-575/...-350-..-B 350 74.0 (*) 147.9 301
TPD32-EV-575/...-420-..-B 420 61.6 (*) 123.3 362
TPD32-EV-575/...-500-..-B 500 51.8 (*) 103.5 431
TPD32-EV-575/...-650-..-B 650 39.8 (*) 79.6 560
TPD32-EV-575/…-700-...-C 700 37.0 74.0 603
TPD32-EV-575/…-1000-...-C 1000 25.9 51.8 861
TPD32-EV-575/...-1050-…-C 1050 24.7 49.3 904
TPD32-EV-575/...-1300-...-D 1300 19.9 39.8 1119
TPD32-EV-575/...-1600-...-D 1600 16.2 32.4 1378
TPD32-EV-575/...-2000-...-D 2000 12.9 25.9 1722
TPD32-EV-575/...-2300-...-D 2300 11.3 22.5 1980
TPD32-EV-690/...-1010-…-E 1010 25.6 51.3 870
TPD32-EV-690/...-1400-…-E 1400 18.5 37.0 1205
