gefran TPD32-EV-500 series User Manual

—————— Instruction manual ——————
327
6.17.2.1 Compensations and closing of the tension loop
OPTIONS
Torque winder
Torque calculat
Comp calculat
[1183] IntacccalcEn
[1182]
Timeacc/decmin[s]
[1212] Acc/declter[ms]
[1184] Lineacc[%]
[1185] Linedec[%]
[1186] Linefaststop[%]
[1188] Lineaccstatus
[1189] Linedecstatus
[1190] Linefstpstatus
[1171] VariableJcomp[%]
[1172]
ConstantJcomp[%]
[1192] ActvarJcomp[%]
[1191] ActconstJcomp[%]
[1173] Matwidth[%]
[1174] Staticf[%]
[1175] Dinamicf[%]
[1287] StaticfZero
[1213] Actualcomp[%]
[1214] ClosedloopEn
[1208] Closeloopcomp
Parameter description No.
Value
Standard
Conguration
min max
Factory
American
Factory
Standard
Int acc calc En
Enabled(1)/Disabled(0)
1183 0 1 Enabled(1) Enabled(1)
*
Time acc/dec min [s]
1182 0.15 300.00 9.01 9.01
Acc/dec lter [ms]
1212 0 5000 30 30
Line acc [%]
1184 0.00 100.00 100 100
Line dec [%]
1185 0.00 100.00 100 100
Line fast stop [%]
1186 0.00 100.00 100 100
Line acc status
1188 0 1 OFF OFF
*
Line dec status
1189 0 1 OFF OFF
*
Line fstp status
1190 0 1 OFF OFF
*
Variable J comp [%]
1171 0.00 199.99 0 0
Constant J comp [%]
1172 -100.00 +100.00 0 0
Act var J comp [%]
1192 - 200.00 0 0
Act const J comp [%]
1191 - 200.00 0 0
Mat width [%]
1173 0.00 100.00 100 100
Static f [%]
1174 0.00 199.99 0 0
Dinamic f [%]
1175 0.00 199.99 0 0
Static f Zero
Enabled(1)/Disabled(0)
1287 0 1 Disabled(0) Disabled(0)
Actual comp [%]
1213 -200 +200
**
Closed loop En
Enabled(1)/Disabled(0)
1214 0 1 Disabled(0) Disabled(0)
Close loop comp
1208 -32767 +32767
* Thisparametercanbesetonaprogrammabledigitalinput.
**Thisparametercanbesetonaprogrammabledigitaloutput.
