330
11
Base Frame Sub-Assy
1
1284100122
12
Left Side Plate
1
01314712P
13
Right Side Plate
1
01314713P
14
Electric Box Assy
1
1394100374
15
Cable Cross Loop
1
26900000008
16
Main Board
1
30223000020
17
Main Board
1
30223000021
18
XY capacitor
1
33020201
19
XY capacitor
1
33030013
20
High Frequency Transformer
1
43110030
21
Fuse
1
46010055
22
Radiator
1
49010252
23
Main Board
1
30228000010
24
Terminal Board
1
42010264
25
Radiator
1
49010252
26
Filter Board
1
30228000015
27
Main Board
2
30229009
28
Radiator
1
49010252
29
Magnetic Ring
1
49010104
30
Magnetic Ring
6
49010109
31
Terminal Board
1
42010247
32
Terminal Board
1
42018000026
33
Reactor
1
4313017401
34
Rectifier
1
46010604
35
Radiator
2
49018000001
36
Radiator
1
49018000002
37
Bolt
1
70210051
38
Cable Clamp
21
71000151
39
Cable Tie
9
7102026504
40
Cable Cross Loop
1
76510021
41
Front Panel (left)
1
01544100003P
42
Front Panel (right)
1
01544100005P
43
Rear Grill
1
1574100001
44
Tube Clip
1
21400053
45
Tube Clip
1
21400055
46
Filter
1
7218603
47
4-way Valve
1
43000339
48
4-Way Valve Sub-Assy
1
4144100002
49
Temp Sensor Sleeving
2
5212423
50
Nozzle for Adding Freon
2
6120012
51
4-way Valve
1
43000339
52
Strainer
1
7415200002
53
One way Valve
1
7335210
54
Oil Balancing Tube Sub-assy 1
1
4224100273
55
Cut off Valve
1
7130239
56
Strainer
2
7415200002
57
Electromagnetic Valve
1
43000054
58
Discharge Tube Sub-assy
1
4534100081
59
Strainer
1
7415200002
