3
pipe
Connecting way
Connect
with horn
mounth
Connect with
horn mounth
Connect with
horn mounth
Welding
connection
Welding
connection
Net weight
kg
113
113
113
295
295
Minimum circuit
current
A
27.0
31.0
33.0
16.1
20.9
Maximum fuse
current
A
32.0
32.0
40.0
20.0
25.0
External
dimension
(W×D×H)
mm
900×340×1
345
900×340×134
5
900×340×134
5
1340×765×16
05
1340×765×16
05
1) Test voltage of GMV-S120WL/A-S, GMV-S140WL/A-S, GMV-S160WL/A-S is
220V~50HZ; test voltage of GMV-S224W/A-X, GMV-S280W/A-X is 380-415V
3N~50/60HZ.
2) Test working conditions of the above nominal cooling capacity is: indoor dry bulb/wet
bulb temperature (27℃ /19℃), outdoor dry bulb/wet bulb temperature (35℃ /24℃);
Test working conditions of the above nominal heating capacity is: indoor dry bulb/wet
bulb temperature (20℃ /15℃), outdoor dry bulb/wet bulb temperature (7℃ /6℃);
Test working conditions of the above nominal water heating capacity is: initial water
temperature/terminal water temperature (15℃ /52℃), outdoor dry bulb/wet bulb
temperature (20℃ /15℃).
3) Performance parameter of unit will be changed due to improvement of product, there
will be no further notification. For specific parameter please subject to name plate of
product.
4) Heating water power is the average power for collocating with nominal working
condition of hot water generator NRQD16G/A-S.
5) The noise is measured in laboratory, the noise in actual operation will be slightly high
due to change of environment.
6) Sectional area of lead is only applicable to the longest distance range of 15 meters, if it
is over 15 meters, sectional area of lead should be accordingly increased to avoid
overload of current and burning of lead.
7) Select air switch according to maximum fuse current, and select electric wire
acoording to minimum circuit current.
2.2 Performance parameter of hot water generator
Model
NRQD16G/A-S
Hot water heating capacity
kW
4.5(3.6-16)
Hot water yielding volume
L/h
105(75-140)
Floor heating capacity
kW
16
Consumed power for electric heating
kW
3
Power source
-
220-240V ～ 50/60Hz
Water pump
Input power
kW
0.08-0.14
Water flow
m
3
/h
1.7
Delivery lift (available for
external pipeline network)
m
6
