7 - Menu 3 Calibration
Menu 3.1 Speed calibration
Menu 3.1.1 Sprayer
The calibration process is the same for each sensor type. In the following
example a “speed sensor on sprayer“ is used.
Shortcut
1. Press until menu [3.1.1 Sprayer] is shown.
It is possible to connect the speed sensor at different locations. See
chapter 4 - System setup for more about this. They are calibrated in
the following menus:
[3.1.1 Sprayer]Speed sensor on sprayer
[3.1.2 Tractor]Speed sensor on tractor
[3.1.3 Radar]Radar speed sensor
2. Choose with the navigation keys.
3. Press to confirm. The last confirmed sensor is the active speed sensor.
Shortcut
4. Press until menu [3.1.X “Speed abc”] is shown.
5. Choose speed transducer. (Sprayer, Tractor or Radar) [3.1.1 Sprayer]
6. Press to confirm.
7. Press to read PPU value.
μ
ATTENTION! Be aware that even tractor speed sensor and radar speed sensor uses the same connector, then PPU
value may be very different.
The speed transducer can be calibrated theoretically or practically. The
practical method is recommended.
SPEED CALIBRATION
Sprayer
3.1.1
SPRAYER
Constant
3.1.1.1
