Menu 3.3 Boom
Menu 3.3.1 Width
Use the navigation keys to enter boom width.
Press to confirm.
Menu 3.3.2 Number of sections
Use the navigation keys to set number of boom sections.
Press to confirm.
For mistblowers, see section on mistblowers.
Menu 3.3.3 Nozzles/section
Use navigation keys to set correct number of nozzles per section.
Press to continue to next boom section.
Press after the last section.
Menu 3.3.4 End nozzles (optional)
If end nozzles are fitted, set the value to the equivalent coverage by the
boom nozzles. E.g. End nozzle coverage is 2 metres. This is equal to [04
Boom nozzles].
μ
ATTENTION! It is important that the volume applied from the end
nozzle matches the volume applied under the boom. This is a
comparison of volume per minute per length. (Litre/min/metre).
When the end nozzle is active, the area covered and volume
sprayed is calculated and registered. If “Active boom size” is
displayed, it will show an increase when the end nozzle is activated.
XX.X m
3.3.1
NO. OF SECTIONS
Sections XX
3.3.2
NOZZLES/SECTIONS
Section Y XX
3.3.3
END NOZZLES
= XX Boom nozzles
3.3.4
