8 - Menu 4 Toolbox
59
Menu 4.7 Emergency Track
Menu 4.7 Emergency Track
When this menu is entered the “bypass” function is active, so that all
sensors are ignored. The system can be operated manually so it is
possible to fold the boom and drive home. In the menu the sensor
voltages can be checked, which is useful for the HARDI service to solve
the problem.
F: Front potentiometer
R: Rear potentiometer
L: Lock sensor (optional on IntelliTrack; no sensor reads 00.0 Volts)
B: Boom sensor
Lock sensor (optional on IntelliTrack)
If the lock sensor indicates “released” (high voltage) and the track selection switch is in either “auto” or “manual” it is possible
to use the “Left/Right steer” and “Fold inner in” switches disregard any other inputs the Controller recieve from sensors.
If the lock sensor indicates “locked” (low voltage) and the track selection switch is in either “auto” or “manual” it is possible
to use “Fold inner in” switch disregard any other inputs the Controller recieve from sensors. Manual or automatic tracking is
not possible.
If the track selection switch is switched to “align” the trapeze lock is attempted locked disregard any sensor reading. No
automatic align is attemped. Manual or automatic tracking is not possible.
Once the boom is folded into transport position, exit the menu. This will activate the track lock if it is not damaged. As an
extra security, switch power to HC 5500 to OFF and stop oil flow to the sprayer.
€
DANGER! Emergency only. Don’t track with the boom folded! Safety system is disabled.
μ
ATTENTION! Note this menu is only shown if Jobcom hardware is fitted, and the software is enabled.
F: XX.X V R: XX.X V
L: XX.X V B: XX.X V
4.7
