Digital Video Recorder User Manual
123
9.2 Configuring Overlay Channel
Purpose:
You can assign the POS machine to corresponding channel on which you want to overlay.
Steps:
1. Enter the POS settings interface.
Menu > Configuration > POS> Overlay Channel
2. Click to select an analog or IP camera from the camera list on the right, and then click a POS item from the
POS list you want to overlay on the selected camera.
Click or to go to the previous or next page of cameras.
Figure 9. 11 Overlay Channel Settings
3. You can also click to overlay all POS items to the first 8 channels in order. And the is used to clear
all POS overlay settings.
4. Click the Apply button to save the settings.
