HIKVISION DS-7108HGHI-E1 User Manual

Digital Video Recorder User Manual
203
DS-7100HQHI-F1/N
Model
DS-7104HQHI-F1/N
DS-7108HQHI-F1/N
DS-7116HQHI-F1/N
Video/Audio
input
Video compression
H.264+/H.264
Analog video input
4-ch
8-ch
16-ch
BNC interface (1.0Vp-p, 75 Ω), supporting coaxitron connection
Supported HD TVI
input
1080p/25Hz, 1080p/30Hz, 720p/25Hz, 720p/30Hz, 720P/50Hz, 720p/60Hz
Supported AHD
input
720p/25Hz, 720p/30Hz
CVBS input
Support
Audio compression
G.711u
Audio
input/Two-way
audio input
1-ch, RCA (2.0 Vp-p, 1 KΩ)
Video/Audio
output
HDMI/VGA output
1-ch, 1920 × 1080/60Hz,1280 × 1024/60Hz, 1280 ×
720/60Hz, 1024 × 768/60Hz
1-ch, 4K (3840 ×
2160)/30Hz, 2K (2560 ×
1440)/60Hz, 1920 ×
1080/60Hz, 1280 ×
1024/60Hz, 1280 ×
720/60Hz, 1024 ×
768/60Hz
Encoding resolution
When 1080p Lite mode not enabled:
1080p(non-real-time)/720p(non-real-time)/VGA/WD1/4CIF/CIF;
When 1080p Lite mode enabled: 1080p lite/720p lite/VGA/WD1/4CIF/CIF
Frame rate
Main stream: 25fps(P)/30fps(N)
Sub-stream: CIF/QVGA/QCIF ( real time)
Video bitrate
32 Kbps to 6 Mbps
Audio output
1-ch, RCA (Linear, 1KΩ)
Audio bitrate
64 Kbps
Dual-stream
Support
Stream type
Video, Video & Audio
Synchronous
playback
4-ch
8-ch
16-ch
Network
management
Remote connections
128
Network protocols
TCP/IP, PPPoE, DHCP, EZVIZ Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS,
iSCSI, UPnP™, HTTPS, ONVIF
Hard disk
SATA
1 SATA interface
Capacity
Up to 6TB capacity for each disk
External
interface
Network interface
1; RJ45 10M/100Mbps self-adaptive Ethernet interface
1; RJ45
10M/100/1000Mbps
self-adaptive Ethernet
interface
USB port
2 × USB 2.0
General
Power supply
12 VDC
Consumption
(without hard disks)
≤ 8W
≤ 12W
≤ 20W
Working
temperature
-10 ºC to +55 ºC (14 ºF to 131 ºF)
Working humidity
10% to 90%
Dimensions(W × D ×
H)
200 × 200 × 45mm (7.9 × 7.9 × 1.8 inch)
285 × 210 × 45mm (11.2
× 8.3 × 1.8 inch)
Weight(without
hard disks)
≤ 0.8 kg (1.8 lb)
≤ 1.2 kg (2.6 lb)

HIKVISION DS-7108HGHI-E1 Specifications

General

Brand	HIKVISION
Model	DS-7108HGHI-E1
Category	DVR
Language	English
