Digital Video Recorder User Manual
207
DS-7200HGHI-F1/N
Model
DS-7204HGHI-F1/N
DS-7208HGHI-F1/N
DS-7216HGHI- F1/N
Video/Audio
input
Analog video input
4-ch
8-ch
16-ch
BNC interface (1.0Vp-p, 75 Ω)
HD TVI input
720p/25 Hz, 720p/30 Hz
AHD input
720p/25 Hz, 720p/30 Hz
CVBS input
Support
IP video input
1-ch
2-ch
2-ch
Up to 960p resolution
Audio input/Two-way
audio input
1-ch
RCA (2.0 Vp-p, 1 KΩ)
Video/Audio
output
HDMI/VGA output
1-ch, 1920 × 1080/60Hz,1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Audio output
1-ch, RCA (Linear, 1 KΩ)
Encoding
Video compression
standard
H.264+/H.264
Encoding resolution
When 720p stream is connected: 720p/WD1/4CIF/VGA (12fps)/CIF
When 4CIF stream is connected: WD1/4CIF/VGA/CIF
Frame rate
25fps (P)/30fps (N)
Video bitrate
32 Kbps to 4 Mbps
Stream type
Video & Audio/Video
Dual-stream
Support.
Audio compression
standard
G.711u
Audio bitrate
64 Kbps
Synchronous playback
4-ch
8-ch
16-ch
Network
management
Remote connections
128
Network protocols
TCP/IP, PPPoE, DHCP, EZVIZ Cloud P2P, DNS, DDNS, NTP, SADP, SMTP,
NFS, iSCSI, UPnP™, HTTPS
Hard disk
SATA
1 SATA interface
Capacity
Up to 6 TB capacity for each disk
External
interface
Network interface
1; RJ-45 10 M/100 Mbps self-adaptive Ethernet interface
USB interface
Rear panel: 2 × USB 2.0
General
Power supply
12 VDC
Consumption
(without hard disks)
≤ 8W
≤ 12W
≤ 20W
Working temperature
-10ºC to +55ºC (14ºF to 131ºF)
Working humidity
10% to 90%
Chassis
1U chassis
Dimensions
(W × D × H)
260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch)
Weight
(without hard disks)
≤ 1 kg (2.2 lb)
≤ 1 kg (2.2 lb)
≤ 1.2 kg (2.6 lb)
