Digital Video Recorder User Manual
73
5.5 Configuring Event Recording
Purpose:
The event triggered recording can be configured through the menu. Then events include the motion detection,
alarm and VCA events (face detection/face capture, line crossing detection, intrusion detection, region entrance
detection, region exiting detection, loitering detection, people gathering detection, fast moving detection, parking
detection, unattended baggage detection, object removal detection, audio loss exception detection, sudden change
of sound intensity detection, and defocus detection).
The DS-7100 series DVR do not support the VCA alarm.
DS-7200HQHI-F/N series DVR supports 1-ch line crossing detection and intrusion detection. Channels with
audio support audio exception detection.
Steps:
1. Enter the VCA settings interface and select a camera for the VCA settings.
Menu > Camera > VCA
Figure 5. 19 VCA Settings
2. Configure the detection rules for VCA events. For details, see the step 6 in Chapter 9.3 Line Crossing
Detection.
3. Click the icon to configure the alarm linkage actions for the VCA events.
Select Trigger Channel tab and select one or more channels which will start to record when VCA alarm is
triggered.
4. Click Apply to save the settings
Figure 5. 20 Set Trigger Camera of VCA Alarm
