HIKVISION DS-7108HGHI-E1 User Manual

Digital Video Recorder User Manual
210
DS-7300HQHI-F4/N
Model
DS-7304HQHI-F4/N
DS-7308HQHI-F4/N
DS-7316HQHI-F4/N
Video/Audio
input
Video
compression
H.264+/H.264
Video input
4-ch
8-ch
16-ch
BNC interface (1.0Vp-p, 75 Ω), supporting coaxitron connection
Supported
HDTVI input
1080p/25Hz, 1080p/30Hz, 720p/25Hz, 720p/30Hz, 720P/50Hz, 720p/60Hz
Supported AHD
input
720p/25Hz, 720p/30Hz
CVBS input
Support
IP video input
2-ch (up to 6-ch)
2-ch (up to 10-ch)
2-ch (up to 18-ch)
Up to 4.0 MP resolution
Audio
compression
G.711u
Audio input
4-ch, RCA (2.0 Vp-p, 1 KΩ)
Video/Audio
output
CVBS output
Support
HDMI/VGA
output
HDMI: 1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60 Hz,
1280 × 1024/60 Hz, 1280 × 720/60Hz, 1024 × 768/60 Hz
VGA: 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60Hz, 1024 × 768/60
Hz
Encoding
resolution
When 1080p Lite mode not enabled:
1080p(non-real-time)/720p(non-real-time)/VGA/WD1/4CIF/CIF;
When 1080p Lite mode enabled: 1080p lite/720p lite/VGA/WD1/4CIF/CIF
Frame rate
Main stream: 25fps(P)/30fps(N)
Sub-stream: WD1/4CIF (non-real-time); CIF/QVGA/QCIF (real time)
Video bitrate
32 Kbps to 6 Mbps
Audio output
2-ch, RCA (Linear, 1 KΩ)
Audio bit rate
64 Kbps
Dual-stream
Support
Stream type
Video, Video & Audio
Synchronous
playback
4-ch
8-ch
16-ch
Network
management
Remote
connections
128
Network
protocols
TCP/IP, PPPoE, DHCP, EZVIZ Cloud P2P, DNS, DDNS, NTP, SADP, NFS, iSCSI,
UPnP™, HTTPS, ONVIF
Hard disk
SATA
4 SATA interfaces
eSATA
Support
Capacity
Up to 6TB capacity
External
interface
Two-way audio
input
1-ch, RCA (2.0 Vp-p, 1 KΩ) (independent)
Network
interface
1, RJ45 10M/100M/1000M self-adaptive Ethernet interface
USB interface
Front panel: 2 × USB 2.0
Rear panel: 1 × USB 3.0
Serial interface
RS-232, RS-485 (full-duplex), Keyboard
Alarm in/out
16/4
General
Power supply
100 to 240 VAC
Consumption
(without HDD)
≤ 30 W
≤ 40 W
≤ 55 W
Working
temperature
-10 ºC to +55 ºC (14 ºF to 131 ºF)
Working
humidity
10% to 90%
Dimensions
(W × D × H)
445 × 390 × 70 mm (17.5 × 15.4 × 2.8 inch)
Weight
(without HDD)
≤ 5 kg (11.0lb)
