Digital Video Recorder User Manual
88
Steps:
1. Enter the Playback interface.
Menu>Playback
2. Click and select to enter the Event Playback interface.
3. Select Alarm Input, Motion, VCA as the event type, and specify the start time and end time for search.
Figure 6. 6 Video Search by Motion Detection
4. Click Search, and the record files matching the search conditions will be displayed on a list.
5. Select and click button to play back the record files.
You can click Back button to return to the search interface.
If there is only one channel triggered, clicking button takes you to Full-screen Playback interface of
this channel.
If several channels are triggered, clicking button takes you to the Synchronous Playback interface.
Check checkbox to select one channel for playback or select multiple channels for synchronous playback.
The maximum number of channels for synchronous playback supported varies to different models.
Figure 6. 7 Select Channels for Synchronous Playback
6. On the Event Playback interface, you can select the main stream or sub stream from the dropdown list for
playback.
The toolbar in the bottom part of Playback interface can be used to control playing process.
