HIKVISION DS-K1T803F User Manual

Fingerprint Access Control Terminal·User Manual
121
5.12.3 Configuring Status Duration for Door
Purpose:
You can schedule weekly time periods for an access control point (door) to remain open or remain
closed.
In the Door Status module, click Status Duration button to enter the Status Duration interface.
Steps:
1. Click to select a door from the access control device list on the left.
2. On the Door Status Configuration panel on the right, draw a schedule for the selected door.
1) Select a door status brush as Remain Open or Remain Closed.
Remain Open: The door will keep open during the configured time period. The brush is
marked as .
Remain Closed: The door will keep closed during the configured duration. The brush is
marked as .
2) Click and drag on the timeline to draw a color bar on the schedule to set the duration.

HIKVISION DS-K1T803F Specifications

General

Brand	HIKVISION
Model	DS-K1T803F
Category	IP Access Controllers
Language	English
