OPERATOR'S STATION
1-71
CLOSING UPPER FRONT WINDOW
CAUTION: Avoid possible injury while closing win-
dow.
Upper front window comes down very forcefully.
Close window only when sitting in the operator's seat.
Guide window down slowly.
1. Pull out lock pin (3) to unlock window.
2. Slightly move the window forward while pushing lock
release lever (2) to release auto locks (4).
3. Pull window down slowly until it securely catches into
auto locks (4).
NOTE: The wiper and washer will not operate until the upper
front window is completely closed.
4
M1CC-01-031
M1U1-01-028
2
3
To Next Page
