Hitachi ZAXIS 270-3 class User Manual

OPTIONAL ATTACHMENTS AND DEVICES
13-21
WORKING RANGES
ZX110-3, 110M-3 Offset
Model ZX110-3 Offset ZX110M-3 Offset
Category
Item
Off-Set Distance
(0 mm)
(0”)
Max. Off-Set
Distance
(1420 mm)
(4
'
8”)
Off-Set Distance
(0 mm)
(0”)
Max. Off-Set
Distance
(1420 mm)
(4
'
8”)
A: Maximum Digging Reach mm
(ft•in)
7670
(25' 2”)
7140
(23' 5”)
7670
(25' 2”)
7140
(23' 5”)
*1 B: Maximum Digging Depth mm
(ft•in)
5340
(17' 6”)
4800
(15' 9”)
5140
(16' 10”)
4600
(15' 1”)
*1 C: Maximum Cutting Height mm
(ft•in)
7720
(25' 4”)
7370
(24' 2”)
7920
(26' 0”)
7570
(24' 10”)
*1 D: Maximum Dumping Height mm
(ft•in)
5330
(17' 6”)
4980
(16' 4”)
5530
(18' 2”)
5180
(17' 0”)
E: Overall Height mm
(ft•in)
3050
(10' 0”)
2910
(9' 7”)
3140
(10' 4”)
2980
(9' 9”)
F: Overall Length mm
(ft•in)
7320
(24’ 0”)
6830
(22' 5”)
7320
(24' 0”)
6830
(22' 5”)
G: Minimum Swing Radius mm
(ft•in)
2940
(9' 8”)
2500
(8' 2”)
2940
(9' 8”)
2500
(8' 2”)
H: Front-End Attachment Height mm
at Min. Swing Radius (ft•in)
5850
(19' 2”)
5510
(18' 1”)
6050
(19' 10”)
5710
(18' 9”)
NOTE: *1 The dimensions do not include the height of the shoe lug.
M1U1-12-002
C
B
D
A
F
E
G
1420 1420
H
