Hitachi ZAXIS 270-3 class User Manual

OPTIONAL ATTACHMENTS AND DEVICES
13-30
SHOE TYPES AND APPLICATIONS
ZX130LCN-3 2-piece Boom (without Blade)
Shoe Width
500 mm (20”)
Grouser Shoe
600 mm (24”)
Grouser Shoe
700 mm (28”)
Grouser Shoe
800 mm (31”)
Grouser Shoe
Application
For Ordinary Ground
(Standard)
For Weak Footing
(Option)
For Weak Footing
(Option)
For Weak Footing
(Option)
Operating Weight kg
(lb)
13100
(28900)
13300
(29300)
13500
(29800)
13700
(30200)
Base Machine Weight kg
(lb)
10000
(22100)
10200
(22700)
10400
(23200)
10700
(23600)
Cab Height mm
(ft•in)
2740
(9' 0”)
2740
(9' 0”)
2740
(9' 0”)
2740
(9' 0”)
Minimum Ground mm
Clearance (ft•in)
✹
440
(1' 5”)
✹
440
(1' 5”)
✹
440
(1' 5”)
✹
440
(1' 5”)
Undercarriage mm
Length (ft•in)
3750
(12' 4”)
3750
(12' 4”)
3750
(12' 4”)
3750
(12' 4”)
Undercarriage Width mm
(ft•in)
2490
(8' 2”)
2590
(8' 6”)
2690
(8' 10”)
2790
(8' 2”)
Ground Pressure
39 kPa
(0.40 kgf/cm
2
, 5.7 psi)
33 kPa
(0.34 kgf/cm
2
, 4.8 psi)
28 kPa
(0.29 kgf/cm
2
, 4.1 psi)
25 kPa
(0.25 kgf/cm
2
, 3.6 psi)
Shoe Width
500 mm (20”)
Pad Crawler Shoe
Application
For Paved Road
(Option)
Operating Weight kg
(lb)
12900
(28400)
Base Machine Weight kg
(lb)
9900
(22300)
Cab Height mm
(ft•in)
2780
(9' 1")
Minimum Ground mm
Clearance (ft•in)
500
(1' 8")
Undercarriage mm
Length (ft•in)
3830
(12' 7")
Undercarriage Width mm
(ft•in)
2490
(8' 2")
Ground Pressure
38 kPa
(0.39 kgf/cm
2
, 5.5 psi)
NOTE: • The specifications for the front-end attachment are for a 2.10 m (6 ft 11 in) arm with PCSA 0.50 m
3
(0.65 yd
3
) stan-
dard bucket.
• 600 mm (24 in), 700 mm (28 in), 800 mm (31 in) grouser shoe and 500 mm (20 in) pad crawler shoe should not be
used on gravel or rocky ground.
•
✹
The dimensions do not include the height of the shoe lug.
