OPERATOR'S STATION
1-49
WIPER/WASHER SWITCH
The wiper and the window washer are operated using the
wiper/washer switch.
•
Wiper

Turn the wiper/washer switch to the specified position to
operate the wiper.
OFF Position: The wiper stops and is retracted.
INT Position: The wiper operates intermittently at the
interval selected by the switch position as
described below.
INT (Slow): The wiper operates at 8-second interval.
INT (Mid): The wiper operates at 6-second interval.
INT (Fast): The wiper operates at 3-second interval.
ON Position: The wiper operates continuously.
NOTE: • When the front window (upper) is opened, the wiper
and washer will not operate. Even if the front window
(upper) is closed, the wiper and washer will not oper-
ate until the lock pin on the right side is placed in the
lock position. If the front window is opened while
during operating the wiper, the wiper will be retracted
and the washer function is deactivated.
• In case either the wiper or washer is operated with
the front window (upper) opened, or if front window
(upper) is opened while operating either the wiper or
washer, the front window opening alarm buzzer will
sound intermittently at one-second intervals. Close the
front window (upper).
•
Washer (Std. Model)

Press and hold the wiper/washer switch to squirt washer
fluid onto the front window. When the wiper/washer switch
is pressed for more than 2 seconds, the wiper operates until
the switch is released. When the wiper/washer switch is
released, the wiper automatically retracts. While operating
the wiper in the INT mode, when the wiper/washer switch is
pressed, the wiper operation mode is changed to the con-
tinuous operation mode.
IMPORTANT: Washer motor may be damaged if wiper/
washer switch is held for more than 20 sec-
onds, or continually operated with no fluid
in the washer tank.
M178-01-016
Fast
Mid
Slow
Wiper
M1U1-01-018
