Honda TRX500FA 2006 User Manual

(1)
(2)
(5)
(3)
(1) seat lock lever
(2) seat
(3) prongs
(4) hooks
(5) studs
(6) grommets
(5)
(4)
(3)
(6)
(4)
142
Seat Removal
Servicing Your Honda
Saf ety PrecautionsRefer to on page .
Press down on the seat until locks.
Installation
Slide the seat ( ) back and lift it.
Removal
Pull the seat lock lever ( ) at the right side of the seat.
The seat must be removed for the air cleaner, spark plug, battery and
fuse maintenance.
Insert the prongs ( ) into the hooks ( ) on the frame and press the
studs ( ) into the grommets ( ).
1.
2.
1.
2.
1
3
131
6
2
4
5
05/06/08 11:06:13 31HN2650_151
