Honda TRX500FA 2006 User Manual

(4)
(1)
(3) (5) (6) (7)
(2)
(8)
TRX500 FGATRX500 FA
(10) (9)
(4)(3) (5) (6)
(2)
(13)
(15) (14)
(11)
(12)(7)
(4) high oil/coolant
temperature indicator
(5) neutral indicator
(6) reverse indicator
(7) multi-function display
(1) RESET button
(TRX500 FA)
(2) odometer/tripmeter
select button
(3) 4WD indicator
(11) hourmeter/digital clock
select button (TRX500 FGA)
(12) GPS button (TRX500 FGA)
(13) WP button (TRX500 FGA)
(14) plus button (TRX500 FGA)
(15) minus button (TRX500 FGA)
(8) hour select button
(TRX500 FA)
(9) minute select button
(TRX500 FA)
(10) adjust button (TRX500 FA)
14
Indicators & Displays
Instruments & Controls
The indicators and displays on your ATV keep you informed, alert you
to possible problems, and make your riding safer and more enjoyable.
Refer to the indicators frequently. Their functions are described on the
following pages.
USA: Displays read in mph and miles.
Canada: Displays read in km/h and kilometers.
